Trigger - How Execution Begins
Every Step has a type that defines how it triggers. Change the type, and the same pattern works for different use cases. A Step file contains two parts:
Config → defines when and how the Step runs, and gives it a unique name
Handler → the function that executes your business logic
Config → defines when and how the Step runs, and gives it a unique name
Handler → the function that executes your business logic
Read docs
Motia automatically discovers any file ending in .step.ts .step.js or _step.py The filename tells Motia to load it, and the name in the config uniquely identifies the Step inside your system.
api.step.ts
import { ApiRouteConfig, Handlers } from 'motia' export const config: ApiRouteConfig = { name: 'SendMessage',type: 'api',path: '/messages',method: 'POST',emits: ['message.sent'], flows: ['messaging'] } export const handler: Handlers['SendMessage'] = async (req, { emit, logger, state, streams }) => { const { text, userId } = req.body const message = { text, userId, status: 'sent' } await state.set('messages', userId, message) await streams.messages.set(userId, message) logger.info('Message sent', { userId }) await emit({ topic: 'message.sent', data: message }) return { status: 201, body: message } }
api.step.js
exports.config = { name: 'SendMessage',type: 'api',path: '/messages',method: 'POST',emits: ['message.sent'], flows: ['messaging'] } exports.handler = async (req, { emit, logger, state, streams }) => { const { text, userId } = req.body const message = { text, userId, status: 'sent' } await state.set('messages', userId, message) await streams.messages.set(userId, message) logger.info('Message sent', { userId }) await emit({ topic: 'message.sent', data: message }) return { status: 201, body: message } }
api_step.py
config = { name: 'SendMessage',type: 'api',path: '/messages',"method": "POST","emits": ["message.sent"], "flows": ["messaging"] } async def handler(req, context): text = req.get("body", {}).get("text") user_id = req.get("body", {}).get("userId") message = {"text": text, "userId": user_id, "status": "sent"} await context.state.set("messages", user_id, message) await context.streams.messages.set(user_id, message) context.logger.info("Message sent", {"userId": user_id}) await context.emit({"topic": "message.sent", "data": message}) return {"status": 201, "body": message}
event.step.ts
import { EventConfig, Handlers } from 'motia' export const config: EventConfig = { name: 'ProcessMessage',type: 'event',subscribes: ['message.sent'],emits: ['message.processed'], flows: ['messaging'] } export const handler: Handlers['ProcessMessage'] = async (input, { emit, logger, state, streams }) => { const { text, userId, status } = input const processedMessage = { text, userId, status: 'processed' } await state.set('processed', userId, processedMessage) await streams.processed.set(userId, processedMessage) logger.info('Message processed', { userId }) await emit({ topic: 'message.processed', data: processedMessage }) }
event.step.js
exports.config = { name: 'ProcessMessage',type: 'event',subscribes: ['message.sent'],emits: ['message.processed'], flows: ['messaging'] } exports.handler = async (input, { emit, logger, state, streams }) => { const { text, userId, status } = input const processedMessage = { text, userId, status: 'processed' } await state.set('processed', userId, processedMessage) await streams.processed.set(userId, processedMessage) logger.info('Message processed', { userId }) await emit({ topic: 'message.processed', data: processedMessage }) }
event_step.py
config = {"name": "ProcessMessage",type: 'event',"subscribes": ["message.sent"],"emits": ["message.processed"], "flows": ["messaging"] } async def handler(input_data, context): text = input_data.get("text") user_id = input_data.get("userId") status = input_data.get("status") processed_message = {"text": text, "userId": user_id, "status": "processed"} await context.state.set("processed", user_id, processed_message) await context.streams.processed.set(user_id, processed_message) context.logger.info("Message processed", {"userId": user_id}) await context.emit({ "topic": "message.processed", "data": processed_message })
cron.step.ts
import { CronConfig, Handlers } from 'motia' export const config: CronConfig = { name: 'DailySummary',type: 'cron',cron: '0 9 * * *',emits: ['summary.generated'], flows: ['messaging'] } export const handler: Handlers['DailySummary'] = async ({ emit, state, logger, streams }) => { const messages = await state.getGroup('messages') const summary = { total: messages.length, status: 'completed' } await state.set('summaries', 'daily', summary) await streams.summary.set('latest', summary) logger.info('Daily summary generated', { total: summary.total }) await emit({ topic: 'summary.generated', data: summary }) }
cron.stpe.js
exports.config = { name: 'DailySummary',type: 'cron',cron: '0 9 * * *',emits: ['summary.generated'], flows: ['messaging'] } exports.handler = async ({ emit, state, logger, streams }) => { const messages = await state.getGroup('messages') const summary = { total: messages.length, status: 'completed' } await state.set('summaries', 'daily', summary) await streams.summary.set('latest', summary) logger.info('Daily summary generated', { total: summary.total }) await emit({ topic: 'summary.generated', data: summary }) }
cron_step.py
config = { "name": "DailySummary",type: 'cron',"cron": "0 9 * * *","emits": ["summary.generated"], "flows": ["messaging"] } async def handler(context): messages = await context.state.get_group("messages") summary = {"total": len(messages), "status": "completed"} await context.state.set("summaries", "daily", summary) await context.streams.summary.set("latest", summary) context.logger.info("Daily summary generated", {"total": summary["total"]}) await context.emit({ "topic": "summary.generated", "data": summary })
